写一点程序来折腾折腾图片总是有趣的事情,至少可以做完了以后发给朋友炫耀一番。 不过大多数时候得到的回应都是,你用什么P的? 呵呵,我是写程序写的!你才P图,你们全家都P图!#莫名其妙的优越感

最有趣的是当时在读一篇讲 image blending 的论文。说白了就是先把两个图片的 Guassian Pyramid 算出来,然后再出来 Laplacian Pyraimd算出来,然后在每一层把他们 alpha blend 在一起,再全部拼起来。我知道这么说没人听得懂,废话别多说,show me the code

Reduce

采样图片(4个像素点取1个)

convolve the image with given kernel
small = convolveResult[::2, ::2]
return small

Expand

扩展图片(1个像素点扩4个)

initialize big as double size on both dimension.
big[::2, ::2] = image
convolveResult = convolve big with given kernel
return convolveResult *4

Gaussian Pyramid:

创建gaussian Pyramid,其实就是一层层采样

set current to input image
loop until depth reaches
    reduce the current
    append reduce result to pyramid
    set current to reduce result
return pyramid

Laplacian Pyramid:

创建Laplacian Pyramid,其实就是记录每一层采样中流逝的信号,以后还能加回来

for every level of input pyramid p
    compute p[currentLevel] - expand(p[nextLevel])
    append result to pyramid
return pyramid

blend

把每一层通过alpha blend,合起来,组成新的pyramid

for every level
    get black, white and mask of current level
    computer white*mask + black * (1-mask)
    set the result as the level of return pyramid
return pyramid

collapse

把整个pyramid还原成图片,大功告成

current = last level image
loop from the last level to the second level
    expand(current)
    current = expand result + upper level image
return current

来看看成品吧

左边右边两张图,加上一张黑白的mask

黑代表选左边,白代表选右边,接缝处无缝连接,最后合成一张图。

再来一个例子,沙漠和海底



合成一张海底沙漠

下面直接放成品了






不过你觉不觉得有趣,我反正觉得是蛮有趣的,哇哈哈。

感谢@Walker同学投稿~欢迎各路同学交流!
